芯片方案：CC2340R5
工作頻率：2.4GHz
發射功率：8dBm
通信距離：170m
產品尺寸：10*14.5mm 產品重量：0.5±0.1g
產品簡介：E104-BT55SP是一款基于藍牙協議5.3版本的小體積、低功耗藍牙模塊，工作在2.4GHz頻段。E104-BT55SP模塊是億佰特基于德州儀器(TI) 的CC2340R5芯片研發，該藍牙模塊具備48-MHz Arm?Cortex?-M0+處理器,集成平衡-非平衡變壓器，擁有 UART、I2C、SPI、ADC、DMA、PWM等豐富的外設資源，同時全 IO 口引出，方便用戶進行多方位的開發。最大支持 3Mbps 的波特率。
| 主娶參數 | 性能 | 備注 | |
| 小值 | 最大值 | ||
| 電源電壓 | 1.7 | 3.8 | 超過3.8V永久燒毀模塊 |
| 阻塞功率（dBm） | - | 10 | 近距離使用燒毀概率較小 |
| 工作溫度（℃） | -40 | 85 | 工業級 |
| 主要參數 | 性能 | 備注 | |||
| 最小值 | 典型值 | 最大值 | |||
| 正常電壓模式 | 1.7 | 3.3 | 3.8 | ≥3.3V可保證輸出功率 | |
| 通信電平 | - | 3.3 | - | 使用5V TTL有風險燒毀 | |
| 工作頻段（MHz) | 2402 | - | 248O | 支持ISM頻段 | |
| 發射功率（dBm) | -20 | o | 8 | dBm | |
| 功 耗 | 接收靈敏度（dBm） | - | -96 | - | 空中速率為1Mbps |
| 發射電流（mA） | - | 11 | - | 8OdBm | |
| 接收電流（mA） | 10 | ||||
| 休眠電流（uA) | 1 | 默認參數 | |||
| 低功耗電流（uA | 6 | TX=OdBm間隔1s | |||
| 主要參數 | 描述 | 備注 |
| 參考距離 | 170m | 晴朗空曠環境，高度2.0米，88dBm，空速1Mbps |
| 藍牙協議 | BLE5.3 | |
| 通信接口 | I/0 | |
| 封裝方式 | 貼片式 | |
| 外形尺寸 | 14.5*10mm | - |
| 射頻接口 | 板載天線 | 等效阻抗約500 |
| 產品重量 | 0.5g | 士0.1g |
| 引腳序號 | 引腳名稱 | 引腳方向 | 引腳用途 |
| 1 | GND | - | 電源地 |
| 2 | GND | - | 電源地 |
| 3 | DI08 | 輸入/輸出 | 可配置的通用I0口 (CC2340R5手冊） |
| 4 | DI011 | 輸入/輸出 | 可配置的通用I0 口 (CC2340R5手冊） |
| 5 | DI012 | 輸入/輸出 | 可配置的通用I0 口 (CC2340R5手冊） |
| 6 | DI013 | 輸入/輸出 | 可配置的通用I0 口 (CC2340R5手冊） |
| 7 | DI016 | 輸入/輸出 | GPI0，SWD接口：模式選擇或軟件專用，高驅動能力 |
| 8 | DI017 | 輸入/輸出 | GPI0，SWD接口：時鐘、高驅動能力 |
| 9 | DI020_A11 | 輸入/輸出 | 可配置的通用I0 口 (CC2340R5手冊) |
| 10 | DI021_A10 | 輸入/輸出 | 可配置的通用I0 口 (CC2340R5手冊) |
| 11 | DI024_A7 | 輸入/輸出 | 可配置的通用I0口(CC2340R5手冊） |
| 12 | VCC | 輸入 | 1.7V ~3.8V外部供電 |
| 13 | GND | - | 電源地 |
| 14 | RST | 輸入 | 復位，低電平有效，內部上拉到3.3v |
| 15 | DI03_X32P | 輸入/輸出 | GPI0，32-kHz外部品振連接，可選 TCX0輸入 |
| 16 | DI04_X32N | 輸入/輸出 | GPI0，32-kHz外部品振連接 |
| 17 | DI06_A1 | 輸入/輸出 | 可配置的通用I0 口 (CC2340R5手冊） |
| 18 | GND | 電源地 |
